4-19
Electrical Shock Hazard
Disconnect power before servicing.
Replace all parts and panels before
operating.
Failure to do so can result in death or
electrical shock.
1. Unplug washer or disconnect power.
2. Turn off the water supply to the washer.
3. Remove the front access panel (see page
4-9 for the procedure).
REMOVING THE TEMPERATURE SENSOR
4. Disconnect the wire connector from the
temperature sensor.
5. Loosen the 10 mm nut and pull the tem-
perature sensor out of mounting bracket.
Temperature Sensor
Temperature Sensor
Wire Connector
Pull Temperature
Sensor Out Of
Heater
10 mm Nut
To Next Page
