WIKA operating instructions process transmitter, model UPT-2x
14111166.02 04/2015 EN/DE
EN
Appendix 2: Menu tree, basic setting
Basic
setting
1 Scaling 11
Dry
adjustment
111 Min. adjustment
Max. adjustment
Wet
adjustment
112 Min. adjustment
Max. adjustment
Application
12 Unit bar, mbar, ...
Mounting
correction
change
apply
Pressure 121
Level 122 Unit m, cm, ...
Density Density unit
Density value
kg/dm³, lb/ft³
Offset change
apply
Mode 124 Pressure
Level
Volume
Sensor-
temp.
125 °C, °F
Damping
value
13
Volume 123 Scale In Low
High
change
apply
change
apply
Characteristic Linear
Horiz. tank
Spherical tank
Linear. table
Scale Out Unit Volume unit L, m³, gal, in³, ...
Free input
Low 0 %
High 100 %
0 … 99,9 s
Write
protect
14 On/Off 141 On
Off
Change
PIN
142
