Operation4618−1/A1
Winterthur Gas & Diesel Ltd.
2/ 5
SPEED / FUEL
EMERG.
STOP
TELEGRAPH
X
X
X
X
X
X
X
X
2
AST. AHD.
RPM
3
4
5
6
1
013.781/06
FREE END
8
7
1
Fig. 1: Location of Control Air Supply
1 Local control panel 5 Telegraph
2 ME tachometer 6 Emergency stop button
3 WECS−9520 manual control panel 7 Nameplate with instructions
4 Rotary knob (speed / fuel) 8 Instrument panel
