Operation
4618−1/A1
Winterthur Gas & Diesel Ltd.
5/ 5
Button
Function Effect / Procedure
Name Color LED
FUEL
CONTROL
MODE
GREY RED Setting of fuel injection quantity to
WECS−9520.
Adjustable with the rotary knob
(speed / fuel)
LED comes on when FUEL
CONTROL MODE is selected.
If the speed control system
becomes defective, or if fuel
injection quantity adjustment is
necessary
LOCAL
MANUAL
CONTROL
GREY GREEN Transfer from ECR MANUAL
CONTROL to LOCAL MANUAL
CONTROL (Local Control)
Transfer from REMOTE AUTOM.
CONTROL (Remote Control) to
LOCAL MANUAL CONTROL (Local
Control)
After takeover of control, the two
green LED come on
Transfer to LOCAL MANUAL
CONTROL must be accepted at the
control room console
SAFETY
SYSTEM
RESET
GREY GREEN Resets the blocked shut-down
conditions
LED comes on if all shut-down
conditions are the same as those
before and all shut-down signals
can be reset
SHD
OVERRIDE
GREY RED Overrides the shut-down signals
Override reset (LED is on
constantly)
If a shut-down can be overridden,
the LED flashes or comes on
constantly
Goes back to the condition before
(i.e. of a shut-down signal that
stays indicated or is not reset)
SOUND
OFF − ALM
ACKN.
GREY None Sets to off the acoustic alarms (bell
/ buzzer)
Data about the version and a check
of the software on the display
(Shut-down) alarm indications that
flash change to alarm indications
that come on constantly.
Push the button for approximately
five seconds
Local Control Panel
