Operation
5556−2/A1
Winterthur Gas & Diesel Ltd.
5/ 5
2.2 Cutting In Procedure
1) Stop the engine.
2) Remove the inspection cover (6, Fig. 2).
3) Find the position of the related cam (9, Fig. 3).
WARNING
Injury Hazard: Before you operate the turning gear, make sure
that no personnel are near the flywheel.
4) Use the turning gear to turn the engine until the roller (10) of the guide piston (2)
is at the highest position (cam peak).
5) Put the pre-tensioner (6) on to the elastic bolt (3). The pre-tensioner must touch
the pad (4).
6) Use the pre−tensioner (6) for loosening the elastic bolt (3) (see the procedure in
the Maintenance Manual 9403−4).
7) Remove the pre-tensioner (6) (see the procedure in the Maintenance Manual
9403−4).
8) Remove the round nut (5), the elastic bolt (3) and the pad (4).
9) Attach the round nut (5) to the elastic bolt (3) on the pad (4) with your hand.
2.3 Completion
1) Install the inspection cover (5, Fig. 1).
2) Remove the blank flanges (1) (tool 94569a) and (3) (tool 94569).
3) Install the HP fuel pipe (4) (see the Maintenance Manual 8752−1 paragraph 3).
2017−08
Fuel Pump − Cutting Out and Cutting In
