Maintenance0008−1/A1
RT-flex58T-D
Winterthur Gas & Diesel Ltd.
2/ 2
flex Parts:
Fuel Pump Actuator 1
Fuel Pump Actuator 2
Fuel Pump Actuator 3
Fuel Pump 1
Fuel Pump 2
Fuel Pump 3
Servo Oil Pump 2
Servo Oil Pump 1
013.149/05
013.150/05
Supply Unit
FUEL SIDE
DRIVING
END
Crank Angle Sensor Unit
FREE END
Sensor 2
(GT5127C)
Sensor 1
(GT5126C)
FUEL
SIDE
DRAWN FOR 7 & 8
CYLINDERS
Crank Angle Sensor Unit
GEAR WHEEL
I
I
WCH02298
Engine Numbering and Designations
2013-08 / V2
