Xantrex XW User Manual

Specifications
A–4 975-0307-01-01
Environmental Specifications
Regulatory Compliance
Operating temperature -4 to 122 °F (-20 to 50 °C)
Storage temperature -40 to 185 °F (-40 to 85 °C)
Maximum case temperature 140 °F (60 °C)
Operating humidity 5 to 95%
Storage humidity 5 to 95%
Ignition protection None
Safety CSA certified to CSA107.1-01 and UL 458 4th Ed.
including the Marine Supplement
EMC FCC part 15B Class B
Industry Canada ICES-0003 Class B

Xantrex XW Specifications

General

Maximum Power Point Tracking (MPPT)	Yes
Model	XW
Category	Controller
Maximum PV Array Voltage	150V
Nominal Battery Voltage	48V
Output Voltage	48V
