Xantrex XW User Manual

Accessing the XW Auto Generator Start Menu
975-0307-01-01 3–3
Accessing the XW Auto Generator Start Menu
Figure 3-2 Accessing the XW Automatic Generator Start Menu
To access the XW Auto Gen Start Menu, start from the XW System Home Screen....
Enter
To view the Select Device Menu,
press the Enter Button.
To select the XW AGS Menu, use the
navigation buttons to highlight XW
AGS.
Press the Enter Button to select the
XW AGS Menu.
XW System Home Screen
Select Device Menu
Use the XW AGS Menu to change configuration settings, set operating mode, clear fault warnings,
and view device information.

Xantrex XW Specifications

General

Maximum Power Point Tracking (MPPT)	Yes
Model	XW
Category	Controller
Maximum PV Array Voltage	150V
Nominal Battery Voltage	48V
Output Voltage	48V
