Xantrex XW User Manual

Configuration
3–32 975-0307-01-01
User Settings
Use this table to record any customized XW Auto Generator Start settings
for future reference.
Table 3-3 Generator Configuration Settings, Values, Defaults, and User Settings
Setting Values Default
User
Setting
Main Menu Items:
GenMode ManualOn, ManualOff, Automatic ManualOff
Mode Operating/Standby Operating
Configuration Menu Items:
“QT En” Enabled, Off Enabled
“QT Begin” 12:00AM–11:59PM (12-hour clock)
00:00–23:59 (24-hour clock)
9:00PM (12-hour clock)
21:00 (24-hour clock)
“QT End” 12:00AM–11:59PM (12-hour clock)
00:00–23:59 (24-hour clock)
8:00AM (12-hour clock)
8:00 (24-hour clock)
“Gen Type” Type 1 to Type 13 Type 2
Triggers Menu Items:
“Start DCV 30 sec” Disabled, 4.0 V–65.0 V 44.0 V
“Start DCV 15 min” Disabled, 4.0 V–65.0 V Disabled
“Start DCV 2 hr” Disabled, 4.0 V–65.0 V Disabled
“Start DCV 24 hr” Disabled, 4.0 V–65.0 V Disabled
“Stop Float” Enabled, Disabled Disabled
“Stop Absorb” Enabled, Disabled Enabled
“Stop V” Disabled, 4.0 V–65.0 V Disabled
“Temp1” Enabled, Disabled Disabled
“Temp2” Enabled, Disabled Disabled
“Load” Enabled, Disabled Disabled
“Start Load” 10.0 A–33.0 A 10.0 A
“Stop Load” 7.0 A–28.0 A 7.0 A

Xantrex XW Specifications

General

Maximum Power Point Tracking (MPPT)	Yes
Model	XW
Category	Controller
Maximum PV Array Voltage	150V
Nominal Battery Voltage	48V
Output Voltage	48V
