Configuration
3–4 975-0307-01-01
The XW Auto Gen Start Menu
The XW Auto Gen Start menu provides the ability to configure the
changeable parameters, select the generator’s operating mode, clear fault
warnings and view device information.
The XW Auto Gen Start Menu Home Screen is divided into five sections.
• Advanced Settings (Configuration Settings)
• GenMode (Manual on/Manual off/Automatic)
• Mode of Operation (Operating/Standby)
• Clear Fault Warnings
• View Device Info
Figure 3-3
Changing Settings
To change operational settings on the XW AGS
Menu:
1. Use the Navigation Buttons to select the desired
operation.
2. Press Enter to highlight the current value for that
setting. Asterisks (*) indicate the last value set.
3. Use the Navigation Buttons to change the value.
Holding the Navigation Button down without
releasing it will scroll through the values quickly.
4. Press ENTER to select the value.
5. Press Exit twice to return to the XW System
Home Screen.
See Figure 3-4.
Auto Gen Start Menu
To access the advanced settings to configure
specific operational parameters:
• Press the Enter button and the Up and Down
Arrow Buttons at the same time.
See Figure 3-5.
