Xantrex XW User Manual

Operation
4–6 975-0307-01-01
Putting the XW Auto Generator Start in Standby Mode
Use the XW System Control Panel to put the XW Auto Generator Start
into Standby mode.
Figure 4-4 Changing the Mode to Standby
XW System
Home Screen
Select Device
Menu
XW Auto Generator Start Settings Menus
Press the Enter
button when the XW
System Home
Screen is displayed.
Use the Navigation
Buttons to scroll
down to the XW
AGS Menu Item.
Press the Enter
Button when XW
AGS is highlighted.
Use the Navigation
Buttons to scroll down
to the Desired Mode
and press the Enter
Button.
Press the Enter Button
when Desired Mode is
highlighted.
To put the XW Auto Generator Start in Standby Mode:
XW System Control Panel
Enter
1
2
3
Use the Navigation
Buttons to change
the setting from
[Operating] to
[Standby]
Press the Enter
Button.
