Clearing Jams at Door A
1. Remove paper from the left tray, then close the tray.
2. Lift the release lever for door A, then open door A as shown.
WWaarrnniinngg:: To avoid injury, use caution. The area around the fuser can be hot.
CCaauuttiioonn:: Do not touch the transfer belt. Touching the belt can reduce image quality or damage the
transfer belt. Do not touch the transfer roller. Touching the roller can reduce image quality.
300 Xerox
®
AltaLink
®
B8145/B8155/B8170 Series Multifunction Printer User Guide
Troubleshooting
