208 7 Maintenance
2. Rotate the lever on the front left side to
unlock it.
3. Open the drum cartridge cover.
4. Grasping the handle of the drum cartridge
indicated by the displayed message,
carefully pull out the cartridge.
Here we will use cartridge R1 as an
example.
Important
• When pulling out the drum cartridge, grasp it with both
hands so it does not drop.
• Take care to avoid touching any toner adhering to the
drum cartridge.
5. Insert the used drum cartridge into the
plastic bag that comes with the new drum
cartridge. After installing the new drum
cartridge, store the old one in the box the
new cartridge came in.
Important
• After removing a drum cartridge from its box, never
stand it up on its end.
6. Insert the protrusions at the end of the new
drum cartridge (which has a protective
cover attached) into the two holes on the
machine.
To Next Page
