Xerox Phaser 6100 User Guide

A DVANCED P RINTING
4.14
4 In the Overlays window, click Create Overlay.
5 In the Create Overlay window, type a name of up to eight
characters in the File name box. Select the destination
path, if necessary. (The default is C:\Formover.)
6 Click Save. The name appears on the Overlay List box.
7 Click OK or Yes to finish creating.
The file is not printed out. Instead it is stored on your
computer hard disk drive.
NOTE : The overlay document size must be the same as the
documents you print with the overlay. Do not create an overlay
with a watermark.

Xerox Phaser 6100 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	1200 x 600 DPI
Time to first page (black, normal)	15 s
Time to first page (color, normal)	24 s
Print speed (black, normal quality, A4/US Letter)	21 ppm
Print speed (color, normal quality, A4/US Letter)	5 ppm
Internal memory	64 MB
Standard input trays	2
Compatible operating systems	MAC OS, NT4, OS X, Win2000, Win95/98, WinME, WinXP, Win 98se
Recommended operating temperature range (T-T)	15 - 32.5 °C
Media types supported	A-4
Page description languages	GDI
Total input capacity	350 sheets

Weight and Dimensions

Dimensions (WxDxH)	510 x 470 x 405 mm
