Yamaha F50F - Cylinder Head

POWR
Power unit
5-19
6C13G11
Cylinder head
5
No. Part name Q’ty Remarks
1 Cylinder head 1
2Screw 6 ø4
×
20 mm
3Plate 1
4 Engine hanger 1
5Bolt 2 M6
×
20 mm
6Gasket 1
Not reusable
7 Cylinder head cover 1
8Bolt 7 M6
×
20 mm
9O-ring 1
10 Oil filler cap 1
11 Bolt 10 M9
×
93 mm
12 Grommet 4
13 Anode 4
14 Cover 4
15 Bolt 4 M5
×
12 mm
16 Plate 4
17 Bolt 4 M6
×
20 mm
