Yamaha F50F - Electrical Components; Port View

ELEC
Electrical systems
– +
8-3
6C13G11
Electrical components
8
Port view
1
Power trim and tilt relay
2
Starter motor
3
Oil pressure switch
4
Cooling water temperature sensor
5
Rectifier Regulator
6
Ignition coil
7
Starter relay
8
Fuse (30 A) (starter relay)
S6C18160
1
2
3
4
5
6
7
8
