GEN
INFO
General information
1-11
6C13G11
Variable trolling RPM switch (optional)
This device is an optional equipment for tiller handle model.
The idling and/or trolling rpm can be controlled in the range of 620 through 900 r/min with 50 r/min
interval.
Especially for 620 through 700 r/min, the engine rpm is controlled with 40 r/min interval.
Pushing and holding the switch changes rpm continuously at 50 r/min interval.
If engine rpm reaches to the ends of specified range, the rpm is no longer changed.
CAUTION:
Do not modify the variable trolling RPM switch.
Modification such as wire extension, disassembly, etc., can malfunction for the system and/
or damage the electrical components.
NOTE:
Variable trolling RPM switch kit P/N: 6C5-W8186-00
1
Variable trolling RPM switch (optional)
S6C11170
1
