Yamaha F50F - Installing the Upper Case

BRKT
Bracket unit
7-21
6C13G11
Installing the upper case
1. Install the upper and lower mounting
bolts into the swivel bracket
1
simulta-
neously.
2. Install the upper mounting nuts
2
, and
then tighten the nuts to the specified
torque.
3. Install and tighten the lower mounting
nuts
3
.
4. Install the covers
4
, and then tighten the
bolts.
È
High thrust model
T
R
.
.
Upper mounting nut
2
:
24 N·m (2.4 kgf·m, 17.7 ft·lb)
S6C17250
LT
271
LT
572
LT
2
1
3
È
4
