Yamaha F50F - Page 112

POWR
Power unit
5-21
6C13G11
5
No. Part name Q’ty Remarks
1Camshaft 1
2 Oil seal 1
Not reusable
3Gasket 1
Not reusable
4 Retaining bolt 1
5 Washer 7
6 Rocker arm assembly 7
7 Rocker arm assembly 1
8 Valve cotter 16
9 Valve spring retainer 8
10 Valve spring 8
11 Valve spring seat 8
12 Valve seal 8
Not reusable
13 Valve guide 8
14 Exhaust valve 4
15 Intake valve 4
16 Rocker arm shaft 1
17 Bolt 5 M8
×
22 mm
