Yamaha F50F - Page 127

6C13G11
5-36
1
2
3
4
5
6
7
8
9
5
No. Part name Q’ty Remarks
18 Cover 1
19 Bolt 1 M5
×
12 mm
20 Plate 1
21 Bolt 1 M6
×
20 mm
22 Joint 1
23 Hose 1
24 Hose 1
25 Joint 1
26 Hose 1
27 Holder 1
28 Bolt 1 M4
×
8 mm
29 Oil pressure switch lead 1
30 Oil pressure switch 1
31 Oil filter 1
32 Joint 1
33 Gasket 1
Not reusable
34 Plug 1 M14
×
12mm
Exhaust cover
