Yamaha F50F - Page 149

6C13G11
6-6
1
2
3
4
5
6
7
8
9
6
No. Part name Q’ty Remarks
1 Cover 1
2Seal 1
3Bolt 4 M8
×
30 mm
4 Water pump housing 1
5 Insert cartridge 1
6 Impeller 1
7O-ring 1
Not reusable
8 Dowel 2
9 Outer plate cartridge 1
10 Gasket 1
Not reusable
11 Seal 1
12 Plate 1
13 Woodruff key 1
Lower unit (F50, F60)
