Yamaha F50F - Page 173

6C13G11
6-30
1
2
3
4
5
6
7
8
9
6
No. Part name Q’ty Remarks
1O-ring 1
Not reusable
2Bolt 2 M6
×
16 mm
3 Oil seal 1
Not reusable
4 Oil seal housing 1
5O-ring 1
Not reusable
6 Shift rod 1
7 Woodruff key 1
8Bolt 2 M8
×
55 mm
9Bolt 2 M8
×
45 mm
10 Water pump housing 1
11 Seal 1
12 Gasket 1
Not reusable
13 Insert cartridge 1
14 Impeller 1
15 Outer plate cartridge 1
16 Gasket 1
Not reusable
17 Dowel 2
Lower unit (FT50, FT60)
