6C13G11
7-34
1
2
3
4
5
6
7
8
9
6. Install the stator onto the motor base.
NOTE:
Place a clean cloth over the end of the arma-
ture shaft, hold it with a pair of pliers, and
then carefully slide the stator over the arma-
ture.
S6C17520
6
7
6
Power trim and tilt motor
To Next Page
