Starter motor
Type Sliding gear
Output kW 1.4
Cranking time limit Second 30
Brushes
Standard length mm (in) 15.5 (0.61)
Wear limit mm (in) 9.5 (0.37)
Commutator
Standard diameter mm (in) 29.0 (1.14)
Wear limit mm (in) 28.0 (1.10)
Mica
Standard undercut mm (in) 0.8 (0.03)
Wear limit mm (in) 0.2 (0.01)
Charging system
Fuse A 20, 30
Stator coil output peak voltage
(W – W)
at cranking (unloaded) V 13.2
at 1,500 r/min (unloaded) V 42.2
at 3,500 r/min (unloaded) V 96.6
Stator coil resistance
(*1)
at 20 °C (68 °F) (W – W)
Ω
0.52–0.63
Rectifier Regulator output
peak voltage (R – B)
at 1,500 r/min (unloaded) V 13.0
at 3,500 r/min (unloaded) V 13.0
Power trim and tilt system
Trim sensor
Setting resistance (P – B)
Ω
9–11
Resistance (P – B)
Ω
9–288.3
Fluid type ATF Dexron
II
Brushes
Standard limit mm (in) 11.0 (0.43)
Wear limit mm (in) 4.5 (0.18)
Commutator
Standard limit mm (in) 19.0 (0.75)
Wear limit mm (in) 18.0 (0.71)
Mica
Standard undercut mm (in) 1.5 (0.06)
(*1)
The figures are for reference only.
