Yamaha F50F - Page 78

FUEL
Fuel system
4-9
6C13G11
4
No. Part name Q’ty Remarks
1 Fuel rail 1
2Gasket 1
Not reusable
3 Idle speed control 1
4Screw 2 ø5
×
13 mm
5 Wiring harness 1
6O-ring 1
Not reusable
7Screw 2 ø5
×
13 mm
8 Sensor assembly 1
9O-ring 1
Not reusable
10 Collar 2
11 Grommet 2
12 Intake silencer 1
13 Screw 2
14 Throttle position sensor 1
15 O-ring 1
Not reusable
16 Bolt 3 M6
×
16 mm
17 Throttle body assembly 1
S6C14110
T
R
.
.
9 N
·
m (0.9 kgf
·
m, 6.6 ft
·
Ib)
T
R
.
.
4 N
·
m (0.4 kgf
·
m, 3.0 ft
·
Ib)
T
R
.
.
9 N
·
m (0.9 kgf
·
m, 6.6 ft
·
Ib)
24
23
1
22
21
2
T
R
.
.
4 N
·
m (0.4 kgf
·
m, 3.0 ft
·
Ib)
4
5
3
6
9
8
7
13
14
15
18
19
17
16
12
11
10
20
16
4
24
