Yamaha FT50C - Page 201

62Y5A11
7-32
1
2
3
4
5
6
7
8
9
No. Part name Q’ty Remarks
1Bolt 2 M5
×
8 mm
2 Relief valve bracket 2
3Bolt 3 M6
×
45 mm
4 Adapter 1
5 Up-relief spring 1 17.5 mm (0.69 in)
6 Valve support pin 1
7 Relief valve seal 1
8 Down-relief spring 1 14.2 mm (0.56 in)
9 Valve support pin 1
10 Relief valve seal 1
11 Filter 1
12 Gear pump 1
13 O-ring 2
Not reusable
5.8
×
1.9 mm
14 Filter 2
15 O-ring 1
Not reusable
17.8
×
2.4 mm
16 Manual valve 1
17 Circlip 1
Gear pump
