Yamaha FT50C - Page 203

62Y5A11
7-34
1
2
3
4
5
6
7
8
9
No. Part name Q’ty Remarks
1Bolt 2 M5
×
20 mm
2 Washer 2
3 Gear pump bracket 1
4 O-ring 2
Not reusable
5.8
×
1.9 mm
5Spring 2
6 Spacer 2
7 Down-shuttle piston 2
8 Up-shuttle piston 1
9 Manual release spring 1
10 Ball 2
11 Gear pump cover 1
12 Down-main valve 1
13 O-ring 1
Not reusable
14 Valve seal 1
15 Circlip 1
16 Pin 2
17 Drive gear 1
18 Shaft 1
19 Driven gear 1
20 Ball 2
21 Return spring 2
22 Up-main valve 1
23 Valve seal 1
24 Circlip 1
25 Gear pump housing 1
Gear pump
