SPEC
Specifications
2-7
62Y5A11
Pulser coil output peak voltage
(W/R – W/B)
@ cranking 1
(*1)
V6.3
@ cranking 2
(*1)
V3.5
@ 1,500 r/min V 7.4
@ 3,500 r/min V 11.2
Pulser coil resistance
(*2)
(W/R – W/B)
Ω
396–594
CDI unit output peak voltage
(B/O – B, B/W – B)
@ cranking 1
(*1)
V 126
@ cranking 2
(*1)
V 150
@ 1,500 r/min V 151
@ 3,500 r/min V 116
Ignition coil resistance 396–594
Primary coil (O – B)
Ω
0.08–0.11
High-tension cord—
high-tension cord
k
Ω
3.5–4.7
Spark plug gap mm (in) 0.9 (0.035)
Ignition control system
Oil pressure switch kPa
(kgf/cm
2
, psi)
50 (0.5, 7.11)
Thermoswitch (Gy/B – B)
OFF
→
ON °C (°F) 76–84 (169–183)
ON
→
OFF °C (°F) 63–77 (145–170)
Starter motor
Type Bendix
Output kW 1.1
Cranking time limit Second 30
Brushes
Standard length mm (in) 16.0 (0.63)
Wear limit mm (in) 12.0 (0.47)
Commutator
Standard diameter mm (in) 33.0 (1.30)
Wear limit mm (in) 31.0 (1.22)
Mica
Standard undercut mm (in) 0.8 (0.03)
Wear limit mm (in) 0.2 (0.01)
(*1)
Cranking 1: unloaded
Cranking 2: loaded
(*2)
The figures are for reference only.
Item Unit
Model
FT50CEHD FT50CED FT50CET
