1.18 Parameters that Change from the Default Settings with A1-02 [Control Method Selection]
YASKAWA TOEPYAIGA5002A GA500 Programming 111
No. Name Range Unit
Control Method (A1-02 Setting)
OLV/PM
(5)
AOLV/PM
(6)
EZOLV
(8)
E1-09
Minimum Output
Frequency
0.0 - 400.0 0.1 Hz Determined by E5-01 Determined by E5-01 Determined by E5-01
E1-10 Minimum Output Voltage 0.0 - 255.0
*4
0.1 V - - -
F1-09
Overspeed Detection Delay
Time
0.0 - 2.0 0.1 s - 0.0 -
L1-01
Motor Overload (oL1)
Protection
0 - 4 1 4 4 Determined by E9-01
L2-31
KEB Start Voltage Offset
Level
0 - 100
*4
1 V 50 50 50
L3-05
Stall Prevention during
RUN
0 - 3 1 1 - 3
L3-20
DC Bus Voltage
Adjustment Gain
0.00 - 5.00 0.01 0.65 0.65 0.65
L3-21
OVSuppression Accel/
Decel P Gain
0.10 - 10.00 0.01 1.00 1.00 1.00
L3-36
Current Suppression
Gain@Accel
0.0 - 100.0 0.1 - - -
L4-01
Speed Agree Detection
Level
0.0 - 400.0
*1
0.1 0.0 Hz 0.0% 0.0%
L4-02
Speed Agree Detection
Width
0.0 - 20.0
*2
0.1 2.0 Hz 4.0% 4.0%
L4-03
Speed Agree Detection
Level(+/-)
-400.0 - +400.0
*5
0.1 0.0 Hz 0.0% 0.0%
L4-04
Speed Agree Detection
Width(+/-)
0.0 - 20.0
*2
0.1 2.0 Hz 4.0% 4.0%
L8-40
Carrier Freq Reduction Off-
Delay
0.00 - 2.00 0.01 s 0.00 0.00 0.00
L8-90
STPo Detection Level (Low
Speed)
0 - 5000 1 0 80 -
n5-04 Speed Response Frequency 0.00 - 500.00 0.00 Hz - 20.00 -
n8-35
Initial Pole Detection
Method
0 - 2 1 0 1 -
n8-51
Pull-in Current @
Acceleration
0 - 200% 1 50% 0 80%
o1-03
Frequency Display Unit
Selection
0 - 3 1 0 1 1
o1-04 V/f Pattern Display Unit 0 - 1 1 - 1 -
*1 The setting range is 0.0 to 100.0 when A1-02 = 6 [PM Advanced Open Loop Vector].
*2 The setting range is 0.0 to 40.0 when A1-02 = 6 [PM Advanced Open Loop Vector].
*3 The default setting changes when the setting for C6-01 [Normal / Heavy Duty Selection] changes.
*4 This is the value for 200 V class drives. Double the value for 400 V class drives.
*5 The setting range is -100.0 to +100.0 when A1-02 = 6 [PM Advanced Open Loop Vector].
