2.2 A: Initialization Parameters
148 YASKAWA TOEPYAIGA5002A GA500 Programming
No. Name Optimal Value
L3-04 Stall Prevention during Decel 7: Overexcitation/High Flux 3
n3-13 OverexcitationBraking (OEB) Gain 1.40
n3-21 HSB Current Suppression Level 150
The drive saves the parameters in Table 2.15 as User Parameters.
Table 2.15 Parameters Saved as User Parameters with the Conveyor 2 Preset
User Parameter No. Parameter No. Saved Name
A2-01 A1-02 Control Method Selection
A2-02 b1-01 Frequency Reference Selection 1
A2-03 b1-02 Run Command Selection 1
A2-04 C1-01 Acceleration Time 1
A2-05 C1-02 Deceleration Time 1
A2-06 E2-01 Motor Rated Current (FLA)
A2-07 L3-04 Stall Prevention during Decel
A2-08 n3-13 OverexcitationBraking (OEB) Gain
A2-09 n3-21 HSB Current Suppression Level
■ Notes for Elevator Applications
When using the drive for elevator applications, read the safety descriptions and precautions, and safely and correctly
use the device.
Conditions to Open and Close the Brake
Set L4-07 = 0 [Speed Agree Detection Selection = No Detection during Baseblock] to open and close the holding
brake.
When L4-07 = 1 [Detection Always Enabled], the output frequency increases when you input the Run command
although the external baseblock command is input. Because of this, speed detection operates and will open the brake
signal.
• Set Related Parameters
Table 2.16 shows examples of parameter settings to use the terminal P2-C2 as the holding brake open and close
signal.
Table 2.16 Holding Brake Open and Close Signal Setting Example
Brake Open and Close Signal Brake Open and Close Level Adjust
Applicable Control Methods
(A1-02 Settings)
Signal Name Parameter Settings Signal Name Parameter Settings
V/f
(0)
OLV
(2)
Frequency (FOUT) Detection 2
L4-07 = 0 Speed Agree Detection Level L4-01 = 1.0 Hz to 3.0 Hz
*1
x x
H2-03 = 5 Speed Agree Detection Width L4-02 = 0.0 Hz to 0.5 Hz
*1 When A1-02 = 2 [Open Loop Vector], it is the usual setting range. When A1-02 = 0 [V/f Control], set L4-01 to the rated slip frequency of
the motor + approximately 0.5 Hz. If you set the value too low, motor torque will not be sufficient and it will cause motor rollback. Set
the parameter to agree with these conditions at the same time. If you set the value too high, it will cause overshoot at start.
• L4-01 > E1-09 [Minimum Output Frequency]
• L4-01 > L4-02 [Speed Agree Detection Width]
*2 Use L4-02 to adjust the detection width of Frequency Detection 2. If rollback occurs when the motor stops, change the frequency to
approximately 0.1 Hz.
