2.8 H: Terminal Function Selection
YASKAWA TOEPYAIGA5002A GA500 Programming 317
■ H2-42: Mbus Reg 15E0h bit2 Output Func
No.
(Hex.)
Name Description
Default
(Range)
H2-42
(0B5A)
Mbus Reg 15E0h bit2
Output Func
Sets the MFDO for bit 2 of MEMOBUS register 15E0 (Hex.).
F
(0 - 1FF)
■ H2-60: Term MA,MB,MC Secondary Function
No.
(Hex.)
Name Description
Default
(Range)
H2-60
(1B46)
Expert
Term MA,MB,MC
Secondary Function
Sets the second function for terminal MA/MB-MC. Outputs the logical calculation results of the
terminals set to functions by H2-01 [Term MA,MB,MC Function Selection].
F
(0 - FF)
■ H2-61: Term MA,MB,MC Logical Operation
No.
(Hex.)
Name Description
Default
(Range)
H2-61
(1B47)
Expert
Term MA,MB,MC Logical
Operation
Sets the logical operation for the functions set in H2-01 [Term MA,MB,MC Function Selection] and
H2-60 [Term MA,MB,MC Secondary Function].
0
(0 - 8)
Note:
Refer to Output of Logical Operation Results of MFDO on page 310 for more information about the relation between parameter settings and
logical operations.
■ H2-62: Term MA,MB,MC Minimum ON Time
No.
(Hex.)
Name Description
Default
(Range)
H2-62
(1B48)
Expert
Term MA,MB,MC
Minimum ON Time
Sets the minimum ON time that the drive uses to output the logical calculation results from terminal
MA/MB-MC.
0.1 s
(0.0 - 25.0 s)
■ H2-63: Terminal P1 Secondary Function
No.
(Hex.)
Name Description
Default
(Range)
H2-63
(1B49)
Expert
Terminal P1 Secondary
Function
Sets the second function for terminal P1-C1. Outputs the logical calculation results of the terminals
set to functions by H2-02 [Term P1 Function Selection].
F
(0 - FF)
■ H2-64: Terminal P1 Logical Operation
No.
(Hex.)
Name Description
Default
(Range)
H2-64
(1B4A)
Expert
Terminal P1 Logical
Operation
Sets the logical operation for the functions set in H2-02 [Term P1 Function Selection] and H2-63
[Terminal P1 Secondary Function].
0
(0 - 8)
Note:
Refer to Output of Logical Operation Results of MFDO on page 310 for more information about the relation between parameter settings and
logical operations.
■ H2-65: Terminal P1 Minimum ON Time
No.
(Hex.)
Name Description
Default
(Range)
H2-65
(1B4B)
Expert
Terminal P1 Minimum ON
Time
Sets the minimum ON time used to output the logical calculation results from terminal P1-C1.
0.1 s
(0.0 - 25.0 s)
