YASKAWA GPD-506V

Continued
C. Coast w/Timer 1 ( 2 ) : Coast to Stop With Timer 1
When programmed for coast to stop with timer 1, a Run command is ignored if issued during
the time the motor would normally be decelerating (n019 or n021 ), or for the minimum
base block time (n057), whichever is longer.
D. Coast w/Timer 2 ( 3 ) : Coast to Stop With Timer 2
When programmed for coast to stop with timer 2, a Run command is retained, but is not
responded to, until after the time the motor would normally have decelerated to a stop
(n019 or n021 ), or for the minimum base block time (n057), whichever is longer.
5-56
5.25 STOPPING METHOD
Output Frequency
Run Command
Run Command ignored
ON ON ONOFF OFF
Decel Time 1
(n019 )
Coasting
Accel Time 1
(n018)
Output Frequency
Run Command
ON ONOFF
Decel Time 1
(n019 )
Coasting
Accel Time 1
(n018)
