This section describes features of the drive which are defined by programmed settings in
the various parameters in memory. Since most features use more than one parameter,
the descriptions appear in alphabetical order by the function name. In Table 5-1, the
functions are grouped into operational categories. To cross reference a particular
parameter to the features to which it applies, see the listings in Appendix 1, or the Index.
SET-UP
Initialization (Reset), 2-Wire or 3-Wire 5.23 n001
Drive Capacity, Parameters Affected By Table A3-1 ———
Volts/Hertz Patterns, Standard 5.28 A n010
Volts/Hertz Pattern, Custom 5.28 n011 - n017
Input & Output Voltage Setting 5.28 B n003
Thermal Motor Overload Protection 5.26 n033, n034
Digital Operator Display, Re-scaling 5.8 n023
Input Phase Loss Detection 5.29 n083
STARTING
Accel Time 5 . 2 n018, n020
S-Curve Characteristics 5.3 n022
DC Injection Braking at Start 5.7 n016, n068, n070
STOPPING
Stopping Method 5.25 n004
Decel Time 5 . 2 n019, n021
DC Injection Braking at Stop 5.7 n016, n068, n069, n070
Local/Remote Changeover 5.15.1 n111
SPEED CONTROL
Frequency Reference, Upper & Lower Limits 5.12 n031, n032
Jog Reference 5.15 n030, n036 - n040
Speed Reference Selection (Remote/Local) 5.19A n002
Multi-step Speed Setting 5.19B n024 - n030, n037 - n040
Sample/Hold 5.19G n036 - n040
Accel/Decel/Hold 5.19H n036 - n040
Up/Down Frequency Setting 5.19H n040
Table 5-1. List of Features Defined By Parameters
FUNCTION
PARAGRAPH
PARAMETER(S)
REFERENCE
5-1
Section 5. PROGRAMMABLE FEATURES
5.1 GENERAL
