n001 : Parameter Selection / Initialization Factory setting: 1
(Password)
Range: 0 to 9
The following table shows which parameters can be programmed (displayed & changed) or
only displayed when n001 is selected.
By entering either initialization code into n001, a reset to factory configuration
(parameter initialization) is accomplished. The parameters which are NOT affected are:
n005(Motor Rotation), n010(V/f selection), and n115(Inverter kVA Sel).
Know your application before using either Initialization function of n001 . This
parameter must be set to " 0 " to " 3 " for operation.
" 8 " = Factory 2-Wire Control Initialization (Maintained RUN Contact)
" 9 " = Factory 3-Wire Control Initialization (Momentary START/STOP Contact)
Entering either Initialization code resets all parameters to factory settings, and
automatically returns n001 setting to " 1 ". If the drive is connected for 3-Wire
control and this parameter is set to " 8 " (2-Wire Control Initialization), the motor
may run in reverse direction WITHOUT A RUN COMMAND APPLIED. Equipment
damage or personal injury may result.
IMPORTANT
After " 8 " or " 9 " has been entered in n001 , the Motor Rated Current (n033 )
MUST BE REPROGRAMMED to the correct setting for the application. See paragraph
5.26.
5-50
5.23 RESET CODES: 2-WIRE, 3-WIRE INITIALIZATION
2-Wire Control 3-Wire Control
Factory Settings LED LCD LED LCD
n036 0 Reverse RUN 1 STOP Command
n037 2 Ext Fault (NO) -- FWD / REV Cmd (3W)
n038 4 Fault Reset 4 Fault Reset
n039 10 Multi-step Spd 1 10 Multi-step Spd 1
n040 11 Multi-step Spd 2 11 Multi-step Spd 2
LED & LCD Programmable Display Only
Setting Parameters Parameters
0 n001 n002 to n116
1 n001 to n035 n036 to n116
2 n001 to n053 n054 to n116
3 n001 to n116 –––
4 - 7 Not Used
8 Initialization: 2-Wire control
9 Initialization: 3-Wire control
