YASKAWA GPD-506V

When using the Monitor Function, a variety of information will appear on the Digital
Operator display when each of the U-XX (display only) parameters is selected.
CONSTANT DISPLAY
Un- MONITORED ITEM EXAMPLE
01 Frequency reference (Hz) Frequency Ref.
60.0 Hz
02 Output frequency (Hz) Output Freq.
60.0 Hz
03 Output current (A) Output Amps
12.5 A
04 AC output voltage (V) Output Voltage
230 VAC
05 DC Bus voltage (VPN ) DC Bus Voltage
325 VDC
06 Output power (kW ) Output Power
(–) 0.7 kW
07 Input terminal status 00I0I0I0
(1)
08 Drive status 0I0I0I0I
(2)
09 Fault log (last 4 faults)
(3)
Fault History
oC
10 Software number PROM Number
(last 4 digits) : 10XXXX 5110
(4)
11 Elapsed time meter (Hrs) Elapsed Time 1
(lower 4 digits, can be 3456 H
preset in parameter
n066 )
12 Elapsed time meter (Hrs) Elapsed Time 2
(upper 2 digits, can be 12 H
preset in parameter n062 )
13 PID feedback (Hz) 45.0
14 Square root function Square Root N
7557
15 Kilowatt-hour meter KwH Monitor 1
(lower 4 digits) 0.1 KwH
16 Kilowatt-hour monitor KwH Monitor 2
(upper 2 digits) 0
CONSTANT DISPLAY
U- MONITORED ITEM EXAMPLE
(1)
Actual display appearance:
(2)
Actual display appearance:
(3)
See paragraph 6.2 for viewing
of fault log contents.
(4)
"5110" for 230V drives up to
GPD506V-A068 (CIMR-
P5M20151F) and 460V drives
up to GPD506V-B034
(CIMR-P5M40151F)
"5120" for 230V drives
GPD506V-A080 (CIMR-
P5M20181F) and above, and
460V drives GPD506V-B041
(CIMR-P5M40181F) and above
"5130" for all 575V drives
4-6
4.4 MONITOR DISPLAYS
Term. S1 input OPEN
Term. S2 input CLOSED
Term. S3 input OPEN
Term. S4 input CLOSED
Term. S5 input OPEN
Term. S6 input CLOSED
Always OFF
Always OFF
00101010
"Run" status output ON
Reverse Run Command OFF
Drive Ready ON
Drive Fault OFF
Constant write error from Modbus ON
Always OFF
MA-MC ON (closed)
M1-M2 OFF (open)
01010101
