By using the Quick-Start Displays on the Digital Operator, simple programming of the drive
is possible. Following are examples of two methods for setting the acceleration time
(n018 ). The first example shows how to utilize the Accel Quick-Start Display, and the
second example shows how to access parameter n018 through the Program Mode.
EXAMPLE 1: Using Accel Quick-Start Display Display
• Press the DSPL key repeatedly until the " Accel Time 1 "
appears.
• To set the acceleration time to 5 seconds, press the “down
arrow” key until the Digital Operator display reads " 5.0 ".
• Press the ENTER key.
EXAMPLE 2: Using Program Mode
• Press the DSPL key repeatedly until " Parameter n001 "
appears.
• Press the “up arrow” key to access n018 .
• Press the ENTER key. The current set value is displayed.
• To set the acceleration time to 15 seconds, press the “up
arrow” key until the Digital Operator display reads " 15.0 ".
• Press the ENTER key.
Note: Once changed, data will blink until the
ENTER key is pressed.
• Press the DSPL key until " Frequency Ref " appears
and DRIVE LED turns on.
4-5
4.3 BASIC PROGRAMMING
