4.2.1 Description of Quick-Start Displays
By pressing the DSPL key on the Digital Operator while the drive is stopped or running, the
operator can step to each of the sixteen Quick-Start Displays and its associated
display/setting function:
Frequency Ref — Frequency Reference Setting [ n024]
Sets the drive operation speed (Hz), unless the drive has
been programmed for REMOTE Mode operation with run from
external analog speed reference signal. Programmable during run.
Output Freq — Output Frequency Monitor
Displays the output frequency (Hz) at which the drive is
currently operating. This is a monitor only function; the
operator cannot change the displayed value by use of the
keypad.
Output Amps — Output Current Monitor
Displays the level of output current (Amps) that the drive is
currently producing. This is a monitor only function; the oper-
ator cannot change the displayed value by use of the keypad.
Output Power — Output Kilowatt Monitor
Displays the output power (kW) that the drive is currently
producing. This is a monitor only function; the operator cannot
change the displayed value by use of the keypad.
4-2
Press
DSPL
To Next Page
