YASKAWA GPD-506V

- xi -
n001 1 5.23
n002 SEQ = TRM REF = TRM (3) p. A1-1
230.0
(230V)
or
n003 460.0 5.28 B
(460V)
or
575.0
(575V)
n004 Ramp to STOP (0) 5.25
n005 Rotate C.C.W. (0) p. A1-1
n006 REV Allowed (0) p. A1-2
n007 Enabled (1) p. A1-2
n008 Enabled (1) p. A1-2
n009 Enter Key Used (1) p. A1-2
n010 1 5.28 A
n011 60.0 (Note 2) 5.28
230.0
(230V)
or
n012 460.0 (Note 2) p. A1-2
(460V)
or
575.0
(575V)
n013 60.0 (Note 2) p. A1-2
n014 3.0 (Note 2) p. A1-3
n015 17.2 (Note 2) p. A1-3
n016 1.5 (Note 2) p. A1-3
n017 11.5 (Note 2) p. A1-3
n018 10.0 5.2
n019 10.0 5.2
n020 10 5.2
n021 10 5.2
n022 0.2 Sec (1) 5.3
n023 0 5.8
n024 0.0 5.19 B
n025 0.0 5.19 B
n026 0.0 5.19 B
n027 0.0 5.19 B
n028 0.0 5.19 B
n029 0.0 5.19 B
n030 6.0 5.15
n031 100 5.12
n032 0 5.12
n033 (Note 1) (3) 5.26
PARAMETER FACTORY USER PARA.
NUMBER SETTING
(5)
SETTING REF.
QUICK REFERENCE FOR GPD 506/P5 PARAMETERS (FACTORY SET)
n076 2.0 5.20
n077 Disabled (0) 5.21
n078 160 5.21
n079 0.1 5.21
n080 0.0 5.19 F
n081 0.0 5.19 F
n082 Disabled (0) (Note 4)
n083 7 5.29
n084 Disabled (0) 5.22 A
n085 1.00 5.22 E
n086 1.0 5.22 F
n087 10.0 5.22 F
n088 0.00 5.22 F
n089 100 5.22 G
n090 Disabled (0) 5.22 F
n091 0 5.22 F
n092 1.0 5.22 F
n093 Not Inverted (0) p. A1-12
n094 0.0 5.22 I
n095 0.0 5.22 I
n096 Disabled (0) 5.9
n097 (Note 1) 5.9
n098 75 5.9
n099 12 5.9
n100 1 5.9
n101 Enabled (1) 5.16
n102 Coast to STOP (1) 5.16
n103 1 = 0.1Hz (0) 5.16
n104 1 5.16
n105 9600 Baud (2) 5.16
n106 No Parity (0) 5.16
n107 0.0 5.23.1
n108 30 5.23.1
n109 2.0 5.23.1
n110 Disabled (0) 5.16.1
n111 Cycle Extern RUN (0) 5.15.1
n112 6.0
n113 50
n114 0
n115 (Note 1) A3-1
n116 (Note 1) A1-11
n034 STD Motor / 8 Min (1) 5.26
n035 Continue Oper (3) p. A1-5
n036 Reverse RUN (2W) (0) 5.19
n037 Ext Fault (2) 5.19
n038 Fault Reset (4) 5.19
n039 Multi-Step Spd 1 (10) 5.19
n040 Multi-Step Spd 2 (11) 5.19
n041 Fault (0) 5.20
n042 During Running (1) 5.20
n043 FV=MSTR FI=AUX (0) 5.11
n044 4-20 mA (1) 5.11
n045 Memorize FREF (0) 5.14
n046 Not Detected (0) 5.13
n047 80 5.13
n048 100 5.10
n049 0 5.10
n050 100 5.10
n051 0 5.10
n052 Output Freq (0) 5.18
n053 1.00 5.18
n054 (Note 1) 5.5
n055 Not Provided (0) 5.17
n056 110 5.19 E
n057 (Note 1) 5.19 E
n058 (Note 1) 5.19 E
n059 (Note 1) 5.17
n060 0 5.4
n061 Activiate Flt Relay (0) 5.4
n062 0.0 5.6
n063 0.0 5.6
n064 1.0 5.6
n065 Time Running Mtr (1) p. A1-9
n066 0 p. A1-9
n067 0 p. A1-9
n068 50 5.7
n069 0.0 5.7
n070 0.0 5.7
n071 1.0 5.27
n072 Enabled (1) 5.24
n073 170 (Note 1) 5.24
n074 160 (Note 1) 5.24
n075 0.0 5.20
(Note 1) Factory setting depends on GPD 506/P5 rating. See Table A3-1.
(Note 2) Initial value is related to V/f curve selected by n010 setting.
(Note 3) Motor rated current (n033 ) is factory set at a value related to the drive rating (see Table A3-1). User must program this
parameter to the actual FLA of the motor being used. See “Thermal Overload Protection”, on page 5-57.
(Note 4) Only effective when Dynamic Braking components are wired to drive terminals; see Appendix 6.
(Note 5) Factory setting shows display for both LCD and LED digital operators. If only one value is shown, it will appear on either display.
It text is shown followed by a value in parentheses, the text will be displayed on the LCD digital operator, and the value in
parentheses will be displayed on the LED digital operator.
