n014
Frequency – Level of frequency at which drive 0.1 to 399.9 3.0 (Hz) 5.28
Midpoint output voltage will reach
n015
value See Note 1
(Mid
Frequency)
n015
Voltage – Level of drive output voltage when output 0.1 to 255.0 17.2 (VAC) 5.28
Midpoint frequency is at
n014
value
(230V drive)
See Note 1
0.1 to 510.0 34.5 (VAC)
(Mid Voltage) (460V drive) See Note 1
0.1 to 733.1 143.8 (VAC)
(600V drive) See Note 1
n016
Frequency – Lowest level of output frequency 0.1 to 10.0 1.5 (Hz) 5.28
Min. drive will produce
See Note 1
(Min Frequency)
n017
Voltage – Min. Level of drive output voltage 0.1 to 50.0 11.5 (VAC) 5.28
output frequency is at
n016
(230V drive) See Note 1
(Min Voltage) value 0.1 to 100.0 23.0 (VAC)
(460V drive) See Note 1
0.1 to 143.7 25.8 (VAC)
(600V drive) See Note 1
n018
Acceleration Time for drive output to ramp from Fmin. to Fmax. 0.0 to 3600 10.0 (sec) 5.2
Time 1
(Accel Time 1)
Setting increment is 0.1 sec. from 0.0 to 999.9 sec,
See Note 5 and 1 sec. from 1000 to 3600 sec.
n019
Deceleration Time for drive output to ramp from Fmax. to Fmin. 0.0 to 3600 10.0 (sec) 5.2
Time 1
(Decel Time 1)
Setting increment is 0.1 sec. from 0.0 to 999.9 sec,
See Note 5 and 1 sec. from 1000 to 3600 sec.
n020
Acceleration Alternate time for drive output to 0 to 255 10 (sec) 5.2
Time 2 ramp from Fmin. to Fmax.
(Accel Time 2)
n021
Deceleration Alternate time for drive output to 0 to 255 10 (sec) 5.2
Time 2 ramp from Fmax. to Fmin.
(Decel Time 2)
n022
S-curve LED LCD
Selection Setting
Setting 0 to 3 1 5.3
0 No S-Curve
(S-Curve 1 0.2 Sec **
Select) 2 0.5 Sec
3 1.0 Sec
n023
Digital LED LCD
Operator Setting
Setting Display Units 0 to 4999 0 5.8
Display Mode 0 0 ** 0.1 Hz
1 1 0.1 %
(Display Units)
2-39 2-39 rpm
40-4999 40-4999 custom
Table A1-1. Drive Parameters (
nXXX
) – Continued
PARAM.
FUNCTION NAME SETTING FACTORY USER PARA.
NO. (ACTUAL DISPLAY)
DESCRIPTION
RANGE SETTING ** SETTING REF.
A1-3
