YASKAWA GPD-506V

230V Class
Input Power Voltage : 3 Phase 200 / 208 / 220 / 230 VAC + 10%, – 15%
Frequency : 50 / 60 Hz +/– 5%
Output Power Voltage : 0 - 230V (Output cannot be greater than input)
Frequency: 0 - 400 Hz (V/Hz pattern selectable)
NEW OLD RATED NOMINAL 100% CONT. RATED INPUT RECOMMENDED RECOMMENDED
MODEL NO. MODEL NO. kVA HP OUTPUT AMPS AMPS MCCB RATING
(1)
INPUT FUSING
CIMR-P5M GPD506V- (@ 230V) (AMPS) (AMPS)
(2)
20P41F A003 1.2 0.75 3.2 3.9 7 5.6
20P71F A006 2.3 1 & 1.5 6.0 7.2 15 10
21P51F A008 3.0 2 8.0 9.6 15 12
22P21F A011 4.2 3 11.0 13.2 15 17.5
23P71F A017 6.7 5 17.5 21 25 30
25P51F A027 9.5 7.5 & 10 27 33 40 45
27P51F A036 13.0 15 36 44 55 60
20111F A054 19.0 20 54 65 75 90
20151F A068 24 25 68 82 100 100
20181F A080 30 30 80 88 105 125
20221F A104 37 40 104 115 135 175
20300F A130 50 50 130 143 165 200
20370F A160 61 60 160 176 205 250
20450F A192 70 75 192 212 245 300
20550F A248 85 100 248 270 315 400
20750F A312 110 125 312 344 400 400
460V Class
Input Power Voltage : 3 Phase 380 / 400 / 415 / 440 / 460 VAC + 10%, – 15%
Frequency : 50 / 60 Hz +/– 5%
Output Power Voltage : 0 - 460V (Output cannot be greater than input)
Frequency: 0 - 400 Hz (V/Hz pattern selectable)
NEW OLD RATED NOMINAL 100% CONT. RATED INPUT RECOMMENDED RECOMMENDED
MODEL NO. MODEL NO. kVA HP OUTPUT AMPS AMPS MCCB RATING
(1)
INPUT FUSING
CIMR-P5M GPD506V- (@ 460V) (AMPS) (AMPS)
(2)
40P41F B001 1.4 0.75 1.9 2.2 3 3
40P71F B003 2.6 1 & 2 3.6 4.1 7 6
41P51F B004 3.7 3 5.1 5.8 7 8
43P71F B008 6.1 5 8.5 9.6 15 12
44P01F B011 8.6 7.5 11.7 13.2 20 17.5
45P51F B014 11 10 14.8 16.8 20 20
47P51F B021 14 15 21.0 26 30 30
40111F B027 21 20 28.6 33 40 45
40151F B034 26 25 34 40 50 50
40181F B041 31 30 41 46 55 70
40221F B052 40 40 52 58 70 90
40301F B065 50 50 65 72 85 100
40371F B080 61 60 80 88 105 125
40451F B096 73 75 96 106 125 150
40551F B128 98 100 128 141 165 200
40750F B180 130 125 & 150 180 198 230 300
41100F B240 170 200 240 264 305 400
41600F B302 230 250 302 330 380 400
41850F B380 260 300 380 456 525 600
42200F B506 340 350 & 400 506 608 700 400
(3)
43000F B675 460 500 675 810 935 450
(3)
SECTION A. Input Voltage Related Specifications
Table A2-1. Standard Specifications
(table continued on next page)
Appendix 2. SPECIFICATIONS
(1) Molded-case circuit breaker must be rated for at least 18,000 RMS symmetrical amperes interrupting capacity.
(2) Fuses should be of the current-limiting, time-delay type offering protection for semiconductor devices.
(3) Two fuses of this rating are required for each phase.
A2-1
