A2-2
(1) Molded-case circuit breaker must be rated for at least 18,000 RMS symmetrical amperes interrupting capacity.
(2) Fuses should be of the current-limiting time-delay type offering protection for semi-conductor devices.
SECTION A.
Input Voltage Related
Table A2-1. Standard Specifications (Continued)
600V Class drive
Input Power Voltage : 3 Phase 500 / 575 / 600 VAC +/- 10%
Frequency : 50 / 60 Hz +/– 5%
Output Power Voltage : 0 - 600V (proportional to input voltage)
Frequency: 0 - 400 Hz (V/Hz pattern selectable)
RATED NOMINAL 100% CONT. RATED INPUT RECOMMENDED RECOMMENDED
MODEL NO.
kVA HP OUTPUT AMPS AMPS MCCB RATING
(1)
INPUT FUSING
CIMR-P5M
(@ 600V) (AMPS) (AMPS)
(2)
51P51F 2 2 & 3 3.9 4.3 10 10
52P21F 3 3 4.6 5.1 10 10
53P71F 5 5 7.0 7.7 20 15
55P51F 7.5 7.5 & 10 11.0 12.1 20 25
57P51F 10 10 14.0 15.4 20 3
50111F 15 15 19 21 30 40
50151F 20 20 25 28 50 50
50181F 25 25 30 33 60 60
50221F 30 30 36 40 60 70
50301F 40 40 46 51 100 100
50371F 50 50 58 64 100 125
50451F 60 60 69 76 100 156
50551F 75 75 86 95 150 200
50751F 100 100 111 122 225 250
50900F 125 125 & 150 145 160 225 300
51100F 150 200 192 211 300 400
51600F 200 200 224 246 400 500
