YASKAWA GPD-506V

51P51F 2 & 3 NEMA 1 11.02 5.51 7.08 10.47 4.96 9 35 55 90
52P21F 3 NEMA 1 11.02 5.51 7.08 10.47 4.96 9 45 60 105
53P71F 5 NEMA 1 11.81 7.87 8.07 11.22 7.32 13 65 75 140
55P51F 7.5 & 10 NEMA 1 11.81 7.87 8.07 11.22 7.32 14 100 105 205
57P51F 10 NEMA 1 11.81 7.87 8.07 11.22 7.32 14 130 125 255
50111F 15 NEMA 1 14.96 9.84 8.85 14.37 9.29 29 180 150 330
50151F 20 NEMA 1 14.96 9.84 8.85 14.37 9.29 29 250 210 460
50181F 25 NEMA 1 29.53 15.75 11.22 28.74 11.81 97 310 230 540
50221F 30 NEMA 1 29.53 15.75 11.22 28.74 11.81 97 380 340 720
50301F 40 NEMA 1 33.47 22.64 11.81 32.48 18.70 159 430 390 820
50371F 50 NEMA 1 33.47 22.64 11.81 32.48 18.70 159 680 540 1220
50451F 60 NEMA 1 33.47 22.64 11.81 32.48 18.70 159 900 750 1650
50551F 75 NEMA 1 41.34 22.64 12.80 40.35 18.70 198 1000 750 1750
50751F 100 NEMA 1 41.97 22.64 12.80 40.35 18.70 198 1100 1150 2250
50900F 125 & 150 49.21 22.64 12.99 48.23 18.70 267 1150 1200 2350
51100F 200 62.99 22.64 13.98 61.81 18.70 324 1400 1800 3200
51600F 200 62.99 22.64 13.98 61.81 18.70 335 1870 2830 4700
MODEL PHYSICAL DIMENSIONS MOUNTING HEAT LOSS
NO.
NOMINAL ENCLOSURE (IN.) DIM. (IN.) WEIGHT (Watts)
VOLTS
CIMR-P5M
HP TYPE (LB)
HWD H1W1
Heatsink Internal Total
Table A5-1. Drive Size and Weight
Protected
Chassis
6
0
0
V
A5-2
