YASKAWA GPD-506V

Continued
5-38
FWD RUN
(S5) UP
COMMAND
(S6) DOWN
COMMAND
UPPER
LIMIT SPEED
LOWER
LIMIT SPEED
OUTPUT
FREQUENCY*
"SPEED AT SET
FREQUENCY"
SIGNAL
* U = UP (Accel) status; D = DOWN (Decel) status; H = HOLD (constant speed) status;
U1 = At Upper Limit Speed; D1 = At Lower Limit Speed
Up/Down Frequency Setting Timing
DD D DHHHHHH HUUU
U
DD
5.19 MULTI-FUNCTION INPUT TERMINALS (Term. S2-S6)
