14.5 LIO-04/05 Modules
14.5.5 Module Specifications
79
14.5.5 Module Specifications
The following table shows the hardware specifications of the LIO-04/
05 Module.
14.5.6 Input Circuit Specifications
The following table shows the LIO-04/05 Modules input circuit
specifications.
Item Specifications
Name
LIO-04/LIO-05
Model
JAPMC-IO2303/JAPMC-IO2304
Digital Inputs
32 inputs
24VDC, 4.1 mA, combined sink mode/source mode inputs
(DI_00, 01, 16, and 17 also used for interrupts.)
Simultaneously ON Inputs
16 points (8 inputs/common): At ambient temperature of 55C and 24VDC
10 points (5 inputs/common): At ambient temperature of 55C and 28.8VDC
Refer to the following characteristics graph for details.
Digital Outputs
32 outputs
24VDC transistor open-collector outputs, sink mode outputs
Indicators
RUN (green)
ERR (red)
Dimensions (mm)
125 95 (H D)
Mass
80 g
Item Specifications
Inputs
32 points
Input Format
Sink mode, source mode input
Isolation Method
Photocoupler (PS2805-4)
Input Voltage
24VDC (+19.2 to +28.8V)
Input Current
4.1 mA (typ.)
ON Voltage/Current
15VDC min./2.0 mA min.
OFF Voltage/Current
5VDC min./1.0 mA min.
ON Time/OFF Time
ON: 0.5 ms Max
OFF: 0.5 ms Max
Number of Commons
8 points
