14.5 LIO-04/05 Modules
14.5.7 Digital Input Circuit (Sink Mode Input) Connection Example
80
14.5.7 Digital Input Circuit (Sink Mode Input) Connection
Example
14.5.8 Digital Input Circuit (Source Mode Input) Connection
Example
5.6kΩ/ 0.5W
Vcc
DICOM
+24V
DI_IN
Input register
0
24
Photocoupler
R
R
R
R
5.6kΩ/ 0.5W
Vcc
DICOM
+24V
DI_IN
Input register
0
24
R
R
R
R
Photocoupler
