YASKAWA SGDV - Page 383

11.2 List of Parameters
11-23
11
Appendix
Pn50B
Input Signal Selection 2 0000 to FFFF − 6543 After restart Setup
Parameter
No.
Name
Setting
Range
Units
Factory
Setting
When
Enabled
Classification
Reference
Section
4th
digit
3rd
digit
2nd
digit
1st
digit
n.
0 to F Same as /S-ON, the setting of 2nd digit of Pn50A
/P-CL Signal Mapping (Torque Limit when ON (L-level)) (Refer to 5.8.2.)
N-OT Signal Mapping (Overtravel when OFF (H-level)) (Refer to 5.2.3.)
0
1
2
3
4
5
6
7
8
9
A
B
C
D
E
F
Reverse run allowed when CN1-40 input signal is ON (L-level).
Reverse run allowed when CN1-41 input signal is ON (L-level).
Reverse run allowed when CN1-42 input signal is ON (L-level).
Reverse run allowed when CN1-43 input signal is ON (L-level) .
Reverse run allowed when CN1-44 input signal is ON (L-level).
Reverse run allowed when CN1-45 input signal is ON (L-level).
Reverse run allowed when CN1-46 input signal is ON (L-level).
Reverse run prohibited.
Reverse run allowed.
Reverse run allowed when CN1-40 input signal is OFF (H-level).
Reverse run allowed when CN1-41 input signal is OFF (H-level).
Reverse run allowed when CN1-42 input signal is OFF (H-level).
Reverse run allowed when CN1-43 input signal is OFF (H-level).
Reverse run allowed when CN1-44 input signal is OFF (H-level).
Reverse run allowed when CN1-45 input signal is OFF (H-level).
Reverse run allowed when CN1-46 input signal is OFF (H-level).
/ALM-RST Signal Mapping
(Alarm reset when OFF (H-level) to ON (L-level))
(Refer to 5.10.1.)
0
1
2
3
4
5
6
7
8
9
A
B
C
D
E
F
Active on the falling edge of CN1-40 input signal.
Active on the falling edge of CN1-41 input signal.
Active on the falling edge of CN1-42 input signal.
Active on the falling edge of CN1-43 input signal.
Active on the falling edge of CN1-44 input signal.
Active on the falling edge of CN1-45 input signal.
Active on the falling edge of CN1-46 input signal.
Reserved (Do not change.)
Sets signal OFF.
Active on the rising edge of CN1-40 input signal.
Active on the rising edge of CN1-41 input signal.
Active on the rising edge of CN1-42 input signal.
Active on the rising edge of CN1-43 input signal.
Active on the rising edge of CN1-44 input signal.
Active on the rising edge of CN1-45 input signal.
Active on the rising edge of CN1-46 input signal.
0 to F Same as /S-ON, the setting of 2nd digit of Pn50A
/N-CL Signal Mapping (Torque Limit when ON (L-level)) (Refer to 5.8.2.)
(Refer to 5.10.1)
(Refer to 5.2.3)
(Refer to 5.8.2)
(Refer to 5.8.2)
