This chapter describes how to interpret the model numbers
of SGMCS Servomotors and gives their specifications, rat-
ings, and external dimensions.
7.1
Model Designations . . . . . . . . . . . . . . . . . . 7-3
7.2
Specifications and Ratings . . . . . . . . . . . . . 7-4
7.2.1 Small-Capacity, Coreless Servomotors:
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-4
7.2.2 Small-Capacity, Coreless Servomotors:
Ratings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-6
7.2.3 Small-Capacity, Coreless Servomotors:
Torque-Motor Speed Characteristics . . . . . . . . . 7-7
7.2.4 Small-Capacity, Coreless Servomotors:
Servomotor Overload Protection Characteristics . . 7-8
7.2.5 Medium-Capacity Servomotors, with Cores:
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-9
7.2.6 Medium-Capacity Servomotors, with Cores:
Ratings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-11
7.2.7 Medium-Capacity Servomotors, with Cores:
Torque-Motor Speed Characteristics . . . . . . . . 7-12
7.2.8 Medium-Capacity Servomotors, with Cores:
Servomotor Overload Protection Characteristics . . 7-13
7.2.9 Allowable Load Moment of Inertia . . . . . . . . . . . 7-14
7.3
External Dimensions . . . . . . . . . . . . . . . . . 7-16
7.3.1 Small-Capacity, Coreless Servomotors . . . . . . . 7-16
7.3.2 Medium-Capacity Servomotors with Cores . . . . 7-20
7.3.3 Connector Specifications . . . . . . . . . . . . . . . . . 7-22
Specifications,
Ratings, and External
Dimensions of
SGMCS Servomotors
7
