4.5 Trial Operation of Servomotor with Brakes
4-11
4
Trial Operation
4.5 Trial Operation of Servomotor with Brakes
Observe the following precautions when performing a trial operation of servomotor with brake.
• When checking the brake operation, take advance measures to prevent vibration due to gravity acting on the
machine or external forces.
• Check the servomotor operation and holding brake operation with the servomotor separated from the
machine. If both operations are correct, connect the servomotor and perform trial operation.
Holding brake operation of the servomotor with brake can be controlled the brake interlock output (/BK) sig-
nal of the SERVOPACK.
For wiring on a servomotor with brakes, and setting parameters, refer to 5.2.4 Holding Brakes
4
Turn ON the power to the machine (host controller) and then check that the SERVO-
PACK is servo OFF status. Check again that the protective function in step 1 operates
normally.
Note: For steps 4 to 8, take advance measures for emergency stop so that the servo-
motor can stop safely when an error occurs during operation.
5.2.5 Stopping Servomo-
tors after /S_ON Turned
OFF or Alarm Occur-
rence
5
Perform trial operation with the servomotor connected to the machine, following
each section in 4.3 Trial Operation for Servomotor without Load from Host Refer-
ence.
Check that the trial operation is completed with as the trial operation for servomotor
without load. Also check the settings for machine such as reference unit.
4.3 Trial Operation for
Servomotor without Load
from Host Reference
6
Check the settings of parameters for control used set in step 2 again.
Check that the servomotor rotates matching the machine operating specifications.
7
Adjust the servo gain and improve the servomotor response characteristics, if neces-
sary.
6 Adjustments
8
Write the parameters set for maintenance in 11.4 Parameter Recording Table.
Then the trial operation with the servomotor connected to the machine is completed.
Note: If the JUSP-OP05A digital operator is used, parameters can be saved. Sig-
maWin+, which is a tool for supporting the servo drive, can then manage the
saved parameters in files.
11.4 Parameter Record-
ing Table
Step Operation Reference
Note: The servomotor will not be broken in completely during the trial operation.
Therefore, let the system run for a sufficient amount of additional time to
ensure that it is properly broken in.
