Configuring Each Function
3-24
HW1484764
3.5.5. Checking the Interrupt Job Settings
To check the interrupt job settings, use the following steps:
Select {JOB} - {INTERRUPT JOB} under the main menu to check the interrupt job settings.
・ Output signal: OUT#4089
・ Level 0, signal: IN#4090, job name: SYS_INT_AVOID_R1
Do not change or delete the interrupt job named SYS_INT_AVOID_R1 for the avoidance function or
its settings.
