viii
HW1484764
<YRC1000/YRC1000micro>
Descriptions of the programming pendant keys, buttons, and displays are shown as
follows:
Equipment
Manual Designation
Programming
Pendant
Character Keys
/Symbol Keys
The keys which have characters or symbols
printed on them are denoted with [ ].
e.g. [ENTER]
Axis Keys
/Numeric Keys
[Axis Key] and [Numeric Key] are generic names
for the keys for axis operation and number input.
Keys pressed
simultaneously
When two keys are to be pressed simultaneously,
the keys are shown with a “+” sign between them,
e.g. [SHIFT]+[COORD].
Mode Switch
Mode Switch can select three kinds of modes that
are denoted as follows: REMOTE, PLAY or
TEACH.
(The switch names are denoted as symbols)
Button
The three buttons on the upper side of the
programming pendant are denoted as follows:
START, HOLD, or EMERGENCY STOP.
(The button names are denoted as symbols)
Displays
The menu displayed in the programming pendant
is denoted with { }.
e.g. {JOB}
8/105
